The Primary Calibrator 4046 by TSI is a field-portable volumetric flow calibrator covering a range of 2.5–300 LPM with an accuracy of ±2% and a clear digital display for real-time flow rate readout while making pump adjustments. Traceable to NIST standards and powered by alkaline batteries for cordless use, it is designed for calibrating and verifying medium to high-volume air sampling pumps used in industrial hygiene, environmental, and occupational health sampling programs where accurate, documented flow verification is required before and after sample collection.

Choose Your Option

Rent for flexible short-term use or purchase to own

Rent
Purchase
Rental Rates
Daily
$75.00
Weekly
$180.00
Monthly
Contact for pricing
Reference rates only. You get the best rate calculation - actual price based on your selected rental dates.
See more product details
Need Help Choosing?
Our rental specialists can help you select the right equipment for your specific application.
Call 866-736-8347
1
Choose Purchase Option
Rent short-term or buy to own
Required
Rental Period What are these dates?

No rental period selected

Set your dates to see pricing.

Rental Period What are these dates?
—
Important: These dates apply to your entire cart. Changing dates will affect pricing for all rental items in your cart.

Need equipment sooner than the dates shown? We can often accommodate rush rentals. Call us at 866-736-8347 to confirm availability.

Used Equipment: This equipment has been previously used and tested. It may show signs of wear but is fully functional and inspected.

Your Configuration

4046 (2.5-300 LPM) by TSI -Primary Calibrator
unit quantity
× $75.00
$75.00 Select dates
Subtotal:
$75.00
Select dates
Technician verified and tested instrumentation before every rental
Expert support available by phone and email
Fast delivery and flexible rental terms
What flow range does the TSI 4046 cover?
2,500 to 300,000 mL/min (2.5 to 300 LPM). That is the highest flow range of any calibrator in our fleet, aimed at high-volume samplers and large-flow equipment rather than personal sampling pumps.
What kind of equipment actually needs 300 LPM?
High-volume air samplers, large bioaerosol samplers and ventilation equipment verification. If your work is personal sampling at 1 to 4 L/min, this calibrator is far larger than you need and the TSI 4146 or a Defender 520M is the better fit.
Does it give continuous readings while I adjust a pump?
Yes. It provides continuous real-time readings, so you can watch the flow respond as you adjust rather than taking a reading, adjusting blind, then re-reading. That makes setting a large sampler to a target flow considerably faster.
Is it a primary calibrator, and does it come with certification?
Yes on both counts. It is a primary standard, and it is supplied with a NIST-traceable calibration certificate. The same unit serves for initial adjustment, formal calibration and periodic field checks, so you are not switching reference instruments partway through a programme.
Can I use it in the field or is it a bench instrument?
It is field portable. Despite covering flows up to 300 LPM it is battery powered, compact and light enough to carry to the sampling location, so you can verify equipment where it is deployed instead of bringing it back to a lab.
How does the 4046 compare with the TSI 4146?
They cover different bands. The 4146 runs 0.01 to 20 LPM, suiting personal pumps through mid-range area sampling. The 4046 starts at 2.5 LPM and reaches 300 LPM. They overlap between 2.5 and 20 LPM, so if all your work sits below 20 LPM the 4146 is the more versatile choice.

Features & Capabilities

Calibration Certificate Available: ✓ Yes
Monitoring Scope: Personal Monitoring

Equipment Specifications

Measurement Type: Primary standard volumetric flow calibration
Measurement Range: 2,500 to 300,000 mL/min (2.5 to 300 LPM)
Sampling Modes: Continuous real-time readings for fast pump adjustment and calibration
Calibration Standard: Supplied with a NIST-traceable calibration certificate
Power Supply: Battery powered
Construction: Compact, lightweight and field portable — the same primary calibrator serves for adjustment, calibration and periodic checks
Intended Use: High-volume calibration of area samplers and high-flow sampling equipment

Kit Contents

4046 Calibrator, 6 Spare AA Batteries, 22mm Inlet Filter, Luer Adapter, Bio-Pump Calibration Adapter, Calibration Adapters (Inlet Adapter with 1/2" to 1/4" Tube Adapter), 1/4” and 1/2” ID Tubing, Mounting Lugs (2 Extra), Flow Chart Assembly Diagram, User Manual, Soft Carrying Case, Calibration Certificate
