4146 (0.01-20 LPM) by TSI - Primary Calibrator

Personal Monitoring
Air Sampling Flow Calibrator Manufacturer: TSI
4146 (0.01-20 LPM) by TSI - Primary Calibrator
4146 (0.01-20 LPM) by TSI - Primary Calibrator
4146 (0.01-20 LPM) by TSI - Primary Calibrator

The Primary Calibrator 4146 by TSI is a field-portable volumetric flow calibrator covering a range of 0.01–20 LPM with a clear digital display for real-time flow rate readout while making pump adjustments. Traceable to NIST standards and featuring a dampening chamber module to stabilize pulsating pump flow, it delivers accurate, documented flow verification across both low and medium flow ranges. It is ideal for calibrating personal air sampling pumps before and after collection of industrial hygiene samples, ensuring compliance with OSHA and NIOSH sampling methodology requirements.

Choose Your Option

Rent for flexible short-term use or purchase to own

Rent
Purchase
Rental Rates
Daily
$65.00
Weekly
$160.00
Monthly
Contact for pricing
Reference rates only. You get the best rate calculation - actual price based on your selected rental dates.
See more product details
Need Help Choosing?
Our rental specialists can help you select the right equipment for your specific application.
Call 866-736-8347
1
Choose Purchase Option
Rent short-term or buy to own
Required
Rental Period What are these dates?

No rental period selected

Set your dates to see pricing.

Rental Period What are these dates?
—
Important: These dates apply to your entire cart. Changing dates will affect pricing for all rental items in your cart.

Need equipment sooner than the dates shown? We can often accommodate rush rentals. Call us at 866-736-8347 to confirm availability.

Used Equipment: This equipment has been previously used and tested. It may show signs of wear but is fully functional and inspected.

Your Configuration

4146 (0.01-20 LPM) by TSI - Primary Calibrator
unit quantity
× $65.00
$65.00 Select dates
Subtotal:
$65.00
Select dates
Technician verified and tested instrumentation before every rental
Expert support available by phone and email
Fast delivery and flexible rental terms
What flow range does the TSI 4146 cover?
10 to 20,000 mL/min (0.01 to 20 LPM). That is the widest single span of any calibrator in our fleet, reaching from low-flow sorbent tube sampling right up through area sampling.
Can one 4146 replace both a low-flow and a standard calibrator?
For most industrial hygiene work, yes. Its 0.01 to 20 LPM span covers sorbent tubes and passive samplers at the bottom end, filter cassettes and cyclones in the middle, and area samplers at the top. That is the main reason to choose it over a Defender, which requires picking a specific range model.
Does it give continuous readings while I adjust a pump?
Yes. Continuous real-time readings let you watch flow respond as you turn the adjustment, rather than reading, adjusting blind and re-reading. It shortens pump setup noticeably when you are calibrating several units in a row.
Is it a primary calibrator, and does it come with certification?
Yes. It is a primary standard supplied with a NIST-traceable calibration certificate, and the same unit covers initial adjustment, formal calibration and periodic field checks.
Is it practical to carry to a sampling site?
Yes. It is battery powered, compact and lightweight, so pre- and post-shift pump checks can be done at the work location rather than back at a lab bench.
When would I need the TSI 4046 instead?
Only when your equipment runs above 20 LPM. The 4046 covers 2.5 to 300 LPM for high-volume samplers and ventilation work. Below 20 LPM the 4146 is the more useful instrument because it also reaches down to 0.01 LPM.

Features & Capabilities

Calibration Certificate Available: ✓ Yes
Monitoring Scope: Personal Monitoring

Equipment Specifications

Measurement Type: Primary standard volumetric flow calibration
Measurement Range: 10 to 20,000 mL/min (0.01 to 20 LPM)
Sampling Modes: Continuous real-time readings for fast pump adjustment and calibration
Calibration Standard: Supplied with a NIST-traceable calibration certificate
Power Supply: Battery powered
Construction: Compact, lightweight and field portable — the same primary calibrator serves for adjustment, calibration and periodic checks
Intended Use: Calibration of personal and area air sampling pumps across a wide flow range

Kit Contents

4146 Calibrator, (6) Spare AA Batteries, Particulate Filter (Use on inlet at all times during calibration), Dampening Module, Tubing Adapters – Black Plastic Luer Adapter and 4146 Inlet Connector Included, (2) Lengths of 1/4” ID Tubing and (1) Length of 1/8” ID Tubing, Mounting Lugs (2 Extra), Flow Chart Assembly Diagram, User Manual, Soft Carrying Case, Calibration Certificate
